Legend

UVS swath: (mirror position: +10degrees)
Juno horizon
Juno visibility limit for features at 1000 km altitude
"Mean" aurora from Hubble Space Telescope FUV images
Extremity of the UVS field of regard
Terminator
UVS field of view (mirror position: +10degrees)
JIRAM field of view
JIRAM swath

Juno footprint according to the VIP4 magnetic field model (Connerney et al, 1998)
Point where the surface magnetic field and the Juno direction are co-aligned
Sub-Juno position
Juno footprint according to the VIPAL magnetic field model (Hess et al, 2011)

Callisto: Callisto longitude
CFP: Callisto footprint
EFP: Europa footprint
GFP: Ganymede footprint
Europa: Europa longitude
Ganymede: Ganymede longitude
Io: Io longitude
IFP: Io footprint spots and tail

Main Oval (MO) in red: The Juno VIPAL footprint is < 5000km from the MO (i.e. Juno is close to MF lines connected to the MO)
Extremities of the UVS field of regard
IFP tail in blue: A portion of the IFP tail is < 2000km from the Juno horizon (useful for vertical extension measurements)
GFP in blue: The GFP is < 5000km from the Juno horizon (useful for vertical extension measurements)
Main Oval (MO) in blue: A portion of the MO is < 5000km from the Juno horizon (useful for vertical extension measurements)
